Product Details:
|
Model NO.: | FL35 | Lift Height: | 3000~5000mm |
---|---|---|---|
Condition: | New | Engine: | Issuzu/Mitsubishi |
Transmission: | Automatic | Transport Package: | Nude Package |
Specification: | 2825*1230*2170 Mm | Trademark: | SNSC |
Origin: | China(Mainland) | HS Code: | 8427209000 |
Supply Ability: | 12000 Units/Year | Cab Location: | Adjustable |
Type: | Ordinary Combustion Forklift | Power: | Gasoline Engine |
Load Capacity: | 1T - 5T | Fuel: | Gasoline |
Load Center: | 500mm | Customization: | Available | Customized Request |
Highlight: | Japan NISSAN K25 Gasoline Forklift,Gasoline Forklift SNSC,SNSC LPG counterbalance forklift |
Model NO. | FL35 |
Lift height | 3000~5000mm |
Condition | New |
Engine | Issuzu/Mitsubishi |
Transmission | Automatic |
Transport Package | Nude Package |
Specification | 2825*1230*2170 mm |
Trademark | SNSC |
Origin | China(Mainland) |
HS Code | 8427209000 |
Supply Ability | 12000 Units/Year |
Cab Location | Adjustable |
Type | Ordinary Combustion Forklift |
Power | Gasoline Engine |
Load Capacity | 1T - 5T |
Fuel | Gasoline |
Load center | 500mm |
Customization | Available |
No. | Specifications | Unit | FL35 |
---|---|---|---|
1 | Power Characteristics | LPG gasoline | |
2 | Rated Capacity | kg | 3500 |
3 | Center of load | mm | 500 |
4 | Lifting height | mm | 3000 |
5 | Free lifting height | mm | 145 |
6 | Forks L×W×H | mm | 1070×125×45 |
7 | Tilt Forward/Backward | ° | 6/12 |
8 | Min.turning radius | mm | 2600 |
9 | Min.ground clearance(Mast) | mm | 120 |
10 | Overhead guard height | mm | 2170 |
11 | Height from seat to overhead guard | mm | 480 |
12 | Front overhang | mm | 545 |
13 | Max.traveling speed(loaded) | km/h | 20 |
14 | Max.lifting speed(loaded/empty) | mm/s | 470/520 |
15 | Drawbar pull/Gradeability | kN/% | 18/20 |
16 | Overall length (with fork) | mm | 3895 |
17 | Overall width | mm | 1230 |
18 | Mast lowered height | mm | 2095 |
19 | Mast extended height | mm | 4265 |
20 | Front Tire | 28×9-15-12PR | |
21 | Rear Tire | 6.50-10-10PR | |
22 | Wheelbase | mm | 1800 |
23 | Tread width (Front/Rear) | mm | 1000/970 |
24 | Curb weight (None-load) | kg | 4450 |
25 | Battery Voltage/Capacity | V/Ah | 12/90 |
26 | Engine Model | JAPAN NISSAN K25 | |
27 | Rated power | kw/r.p.m | 37.4/2300 |
28 | Rated torque | Nm/r.p.m | 176.5/1600 |
29 | Cylinder amount | 4 | |
30 | Bore×Stroke | mm | 89×100 |
31 | Displacement | 2.488 | |
32 | Fuel tank | L | 70 |
33 | Transmission | 1/1 automatic transmission | |
34 | Working pressure | MPa | 17.5 |
SNSC is among the top 3 forklift manufacturers globally, with 130,000 square meters production area, over 500 employees, and annual production capacity of 30,000 units. We maintain 5,000 sets export volume annually, demonstrating our commitment to quality and customer satisfaction.
Our 3.5ton LPG GASOLINE forklift can be delivered by container or ro-ro shipment:
SNSC offers a comprehensive range of forklift solutions:
