Product Details:
Contact Now
Chat Now
|
| Model NO.: | FL18 | Lift Height: | 3000~5000mm |
|---|---|---|---|
| Condition: | New | Powered: | Petrol/Propane/LPG/Gas |
| Transport Package: | Nude Package | Specification: | 2825*1230*2170 Mm |
| Trademark: | 2250x1200x2040mm | Origin: | China(Mainland) |
| HS Code: | 842720900 | Supply Ability: | 12000 Units/Year |
| Cab Location: | Adjustable | Type: | Ordinary Combustion Forklift |
| Power: | Gasoline Engine | Load Capacity: | 1T - 5T |
| Fuel: | Gasoline | Load Center: | 500mm |
| Customization: | Available | Customized Request | ||
| Highlight: | Nissan Forklift FL18,4000lbs Canada Fork Lifter,Fork Lifter Petrol Powered |
||
| Model NO. | FL18 |
| Lift height | 3000~5000mm |
| Condition | New |
| Powered | Petrol/Propane/LPG/Gas |
| Transport Package | Nude Package |
| Specification | 2825*1230*2170 mm |
| Trademark | 2250x1200x2040mm |
| Origin | China(Mainland) |
| HS Code | 842720900 |
| Supply Ability | 12000 Units/Year |
| Cab Location | Adjustable |
| Type | Ordinary Combustion Forklift |
| Power | Gasoline Engine |
| Load Capacity | 1T - 5T |
| Fuel | Gasoline |
| Load center | 500mm |
| Customization | Available |
| Features | Power type | LP/Gasoline | ||
|---|---|---|---|---|
| Rated load | kg | 1500 | ||
| Load center | mm | 500 | ||
| Lifting height | mm | 3000 | ||
| Free lifting height | mm | 115 | ||
| Fork size | L*W*T | mm | 920*100*35 | |
| Mast tilt angle | Front/Rear | . | 6/12 | |
| Min. turning radius | mm | 2060 | ||
| Min.ground clearance | Mast | mm | 105 | |
| Overhead guard height | mm | 2040 | ||
| Front overhang | mm | 400 | ||
| Performance | Max. travelling speed | loaded | km/h | 14.5 |
| Max. lifting speed | loaded | mm/s | 460 | |
| Max. traction force | loaded | KN | 16 | |
| Max. climbing ability | % | 20 | ||
| Dimension | Overall length | without fork | mm | 2250 |
| Overall width | mm | 1086 | ||
| Mast lowered height | mm | 1955 | ||
| Mast extended height | mm | 3860 | ||
| Chassis | Tyre | Front | 6.50-10-10PR | |
| Rear | 5.00-8-10PR | |||
| Wheel base | mm | 1400 | ||
| Wheel thread | Front/Rear | mm | 890/920 | |
| Weight(without load) | kg | 2890 | ||
| Powertrain | Battery | V/AH | 12/90 | |
| Engine | Model | nissan K21 | ||
| Rated power | km/r.p.m | 31.2/2250 | ||
| Rated torque | Nm/r.p.m | 143.7/1600 | ||
| No. cylinder | 4 | |||
| Bore x stroke | mm | 89X83 | ||
| Displacement | L | 2.065 | ||
| Fuel tank capacity | L | 45 | ||
| Transmission/shift | 1/1 automatic transmission | |||
| Operation pressure | Mpa | 14.5 |
Side shifter, Double front tires, Solid tire, Double air filter, Vertical exhaust, fork extension, Cab, Fork positioner, duplex/triplex full free mast
Packing Details: 20GP can hold 3 sets 1.8 tonne dual fuel forklift, 40GP can hold 6 sets 1.8 tonne dual fuel forklift
Delivery Details: About 35 Working Days
