Product Details:
|
Model NO.: | MG20 | ||
---|---|---|---|
Highlight: | 3000kgs Electric Tow Tractor,2000kgs Electric Tow Tractor,2000kgs Battery Operated Tow Truck |
Model NO. | MG20 |
Manufacturer | SNSC |
Model designation | MG30 |
Power unit | Battery |
Operation | Stand-on |
Wheelbase (mm) | 975 |
Service weight (with battery, kg) | 550 |
Axle loading, unladen drive/load (kg) | 350/200 |
Battery weight (kg) | 200 |
Tyre, operator/load side | Rubber |
Tyre size, drive (mm) | Φ230×70 |
Tyre size, load (mm) | Φ150×60 |
Wheels number, front/back | 1X/2 |
Tread, load (mm) | 770 |
Overall height (mm) | 1480 |
Towing coupling height (mm) | 140-240 |
Stand height (mm) | 97 |
Overall length (mm) | 1300 |
Overall width (mm) | 850 |
Ground clearance (mm) | 50 |
Turning radius (mm) | 1160 |
Rated drawbar pull (N) | 750 |
Service brake | Electromagnetic |
Drive motor rating (kw) | 1.5(AC) |
Battery voltage/rated capacity | 24V/210Ah |
Steering System | Mechanical |
Our factory was established in 2010, covering an area of approximately 130,000 square meters with more than 400 employees, including nearly 300 front-line workers, 60 office staff, and 80 technical engineers. We have an annual production capacity of 10,000 forklift units, with daily output of 40 units and exports of 3,000 units annually.
Our products are exported to 130 countries and regions including the UK, France, Spain, Russia, Brazil, Australia, United States, Southeast Asia, Middle East, Africa, and South America.
Our facility features 4 modern production workshops equipped with more than 100 units of large and medium-sized international-standard equipment. We maintain world-class research facilities, intelligent detection systems, and adhere to ISO international quality standards with CE, EPA, and GOST certifications.
Our product line includes three main categories: internal combustion, electric, and storage forklifts, comprising 209 different product types. These are widely used in papermaking, automobile, tobacco, logistics, stone material, and other industries.
